技術參數 Specification
|
型號(TYPE) |
ABE |
ABS |
|||
|
220/240V |
50KA |
100KA |
|||
|
380V |
42KA |
65KA |
|||
|
415V |
35KA |
50/50KA(Ics) |
|||
|
440/460V |
35KA |
50KA |
|||
|
480/500V |
25KA |
45KA |
|||
|
600V |
22KA |
25KA |
|||
|
額定電流 In Rated current In |
500，600A |
||||
|
脫扣器類型 Trip type |
可更換電流塊但不可調 Can change the current module,Unadjustable |
||||
|
電流調整 Current adjust |
更換額定電流插塊 Rated current change current module |
||||
|
瞬時脫扣 Instantaneous Trip |
9-5×In…不可調 9-5×In… Unadjustable |
||||
|
極數 Number of poles |
2，3級 Class 2,3 |
||||
|
接線 Connection |
板前(標準) Front connection(standard) 板后(可選) Rear connection(Available) |
||||
|
安裝 Installation |
螺栓固定 Bolt fixed |
||||
|
使用類型 Standard |
A類符合IEC947-2 A category standard:IEC942-2 |
||||
|
分?jǐn)嗄芰?/span> Icu Breaking capacity Icu |
Ics=100% Icu(ABE，ABS) |
||||
|
35KA/415V…ABE |
|||||
|
In |
2極 2 Pole |
3 極 3 Pole |
可更換的插塊電流值 Canbe inserted to replace the current bolock |
||
|
500A |
ABE802b/500 |
ABE803b/500 |
600A |
||
|
600A |
ABE802b/600 |
ABE803b/600 |
500A |
||
|
50KA/415V…ABE |
|||||
|
In |
2極 2 Pole |
3 極 3 Pole |
可更換的插塊電流值 Canbe inserted to replace the current bolock |
||
|
500A |
ABS802b/500 |
ABS803b/500 |
600 |
||
|
600A |
ABS802b/600 |
ABS802b/600 |
500 |
||
|
可選配件 Available attachments |
輔助觸點 Auxiliary contacts |
○ |
|||
|
報警觸點 Alarm contact |
○ |
||||
|
分勵脫扣器 Shunt release (SHT) |
○ |
||||
|
欠電壓脫扣器 Undervoltage Release (UVT) |
○ |
||||
|
板后接線 Rear connection |
○ |
||||
|
絕緣隔板 Insulation baffles |
○ |
||||
|
尺寸 2/3極 Dimension(mm) 2/3 Pole |
210(W)×280(H) ×113(D) |
||||
外型及安裝尺寸/Dimensions and mounting details
